Overview

The Open-Type Magnetic Rod Rotary Screen Printing Machine combines the high capacity of rotary screen printing with advanced magnetic rod scraper technology, delivering excellent print clarity, even color distribution, and strong penetration—especially on wide, elastic, or chemical fabrics. Its open-type design allows for easy screen loading and maintenance.

Key Features

• Magnetic Rod Scraper System: Adjustable pressure and position for uniform printing on thick and thin fabrics; ideal for large-pattern, high-precision printing.
• Open-Type Structure: Easy access for screen installation and cleaning; supports rotary screens from 640mm to 2412mm circumference, enhancing operational flexibility.
• Servo Motor Drive: Each screen is independently controlled via servo motor and computer synchronization, ensuring high printing precision.
• Smart Control System: Includes automatic slurry pumping, man-machine interface, fault detection, and alarm system for intelligent and efficient operation.
• Durable Construction: Built with stainless steel and aluminum alloy components for strength, stability, and easy maintenance.
• Accurate Blanket Tracking: Automatic deviation correction ensures stable blanket movement and consistent print quality.

Applications

Suitable for a variety of textiles including chemical fabrics, velvet, flannelette, elastic materials, and both narrow and wide fabrics. Offers bright, vivid color results and excellent penetration—making it ideal for high-volume or customized textile printing production lines.

Main Specifications
